Marine Plywood

IS: 710

CPL Marine Plywood is manufactured from imported Gurjan (i.e the logs are 80-90 years matured) timber bonded with high quality Phenol Formaldehyde resin conforming to IS: 848-1974. It is pressed under high pressure and temperature, treated wit specific preservatives of high retention conforming to IS: 5539:1969. It is Boiling water proof at 100° for 108 hours dimensionally stable and ideal for long lasting service.

ADVANTAGES

  • Marine Plywood can withstand rigorous climatic conditions, alternate dry and wet weather
  • It is also termite resistant, borer and powder proof
  • Structurally strong, dimensionally stable and long lasting
  • It can be used seperately under varying climatic conditons

IMPLICATIONS

  • Shuttering, frame work of concrete columns
  • Beams slabs, ships, water tanks and cooling towers
  • Cargo containers, railway coaches, kitchen interiors
  • Buses faces, ceiling and domestic furniture

SPECIFICATIONS

Standard Size

  • 2.44× 1.22 mtr. 2.44×0.92 mtr.
  • 2.14×1.22 mtr. 2.14×0.92 mtr.
  • 1.84×1.22 mtr. 1.84×0.92 mtr.

Standard Thickness

  • 3.5mm, 6mm, 9mm, 12mm, 16mm, 19mm, 25mm

TECHNICAL DATA

  • Timber : Tropical Hardwood
  • Veneer Density : Uniform Balanced Construction
  • Density of Plywood : Approx. 825 Kg/m3
  • Adhesive : BWP IS : 848 - 1974
  • Moisture Content (%): 8% - 12%
  • Glue Sheer Strength (KgF/sq.inch) : Minimum 135
  • Water Resistance Test (KgF/sq.inch): Minimum 110
  • Mycological Test (KgF/sq.inch) : Minimum 110
  • Water Absorption 24 hrs boiling : <3%
  • Bonding : Excellent
  • Guarantee : Lifetime
